1.Automatic control: The rubber press has automatic up and down, automatic exhausting, automatic pressure, pre-heating, automatic constant temperature, press timing, time alarm and other functions, and can realize manual and automatic mode switching.

2.Column: Adopt 40CR material, hard chrome plated surface after quenching + high temperature tempering, the surface hardness can reach HRC55-58.

3.Upper seat, mid-seat, bottom seat (oil cylinder): adopt SOLIDWORKS auxiliary mechanical visual design and QT-500 Ductile iron integral casting by aging passivation treatment ,high strength and high toughness, and tensile strength: 50kgf/mm.

4.Plunger: Made of LG-P cold hard alloy material. High surface hardness, not easy to wear, The depth of the cold and hard layer is 15-20mm, and the hardness HRC60-70 degrees,improves service life of the plunger.

5.The heating plate and support plate are precision-ground from 45# steel and undergo nitriding treatment, delivering high strength and exceptional wear resistance. T-slots can be machined upon customer request.

6.Sealing: The oil cylinder sealing adopt newest design high-tech sealing system, oil-resistant, aging-resistant, and wear-resistant; It features a four-stage sealing structure, ensuring excellent sealing performance, preventing oil leakage and pressure loss.

7.Hydraulic system: The main hydraulic parts adopt JAPAN YUKEN brand, easy to buy and change, reasonable layout, easy to maintain.
