1.Roller: Chrome-plated roller, roller surface hardness can reach 70±2 HSD.

2.Rolling bearing: Automatic aligning roller bearing, high carrying capacity, energy saving more than 5% than the traditional nylon bush.

3.Bearing lubrication: Automatic lubrication device, perspective materials are adopted to facilitate observation and timely replenishment of lubricating oil. Each pipe is equipped with a pressure gauge to prevent pipe clogging, improper lubrication caused by bearing damage

4.Nip adjustment device: Standard by motor automatic nip adjustment. Digital display for greater precision, and adopt PLC touchscreen to adjust it.

5.Ratio gear: forged and carburized chromium molybdenum alloy steel or forged 45# steel quenched and hardened.

6.Gear box (reducer): hard tooth surface reducer, adopt top brand in china, with four-axis three-stage transmission, the safety factor is above 2.0.

7.The frame and base: The frame is welded and annealed, and precision machine processed; the cover is steel and annealed;

8.Stock guide: Standard with manual control, movable. The material is MC nylon.

Option with hydraulic stock guide system for automatic control.

9.Safety Device: four emergency stop buttons, two installed on the front and back of the main machine. And one main control box stop button.

Utilizes electro-hydraulic brakes or emergency stop switches to activate reversing brakes. In emergency situations, the brake-applied roller rotates no more than 1/6 of a revolution.

10.Other configurations: Frequency inverter system, motor nip adjustment device, hydraulic brake
